The RF feeder cable entry point into equipment enclosures experiences high mechanical stress from cable weight, movement, and thermal cycling. This 7/16 DIN flange mount connector series distributes operational loads across a 2-hole or 4-hole bolt pattern instead of a single threaded barrel. This design creates a rigid panel attachment that remains stable under continuous loads, preventing the loosening or fatigue failure associated with threaded bulkhead installations.
Key Features
Flange body in passivated stainless steel or nickel-plated brass ensures long-term structural integrity for outdoor enclosures.
2-hole and 4-hole bolt-down configurations with standardized bolt circle dimensions match common enclosure panel layouts.
Full 360° outer conductor continuity at the panel interface delivers optimal RF grounding.
High-performance silicone O-ring sealing at the panel interface achieves IP67-rated weatherproofing.
Solder cup, crimp, and clamp cable termination options on the cable-side port accommodate various feeder cable types.
Mating interface geometry ensures full compatibility with all standard 7/16 DIN equipment.
Flange mount design withstands full mating torque without the risk of body rotation during installation.
Extended flange configurations are available for thick enclosure walls or specific standoff requirements.
Competitive Advantages
Infrastructure-Grade Quality: Manufactured for long-term deployment to match the expected service life of critical infrastructure installations.
Verified Electrical Performance: Production batches undergo network analyzer sampling to confirm return loss and insertion loss meet specifications before shipment.
Custom Flange Geometry: In-house CNC machining capability supports non-standard bolt circle patterns, extended flanges, and custom panel cutout dimensions.
Compliant Documentation: Quality system batch records, material certificates, and test data packages are available to support procurement qualification.
Typical Applications
Broadcast transmitter building wall entry panels for main feeder cable connections
Communication equipment shelter RF cable penetration and rack connector panels
Satellite ground station equipment enclosure RF feeder entry ports
Microwave link outdoor unit (ODU) housing connector panels
High-power RF amplifier and combiner unit chassis connector panels
Mobile communication vehicle and transportable shelter RF entry panels
High-power RF test cell enclosure feed-through panels
FAQ
Q: How does the flange mount design handle the torque applied during cable connector mating?
A: The bolted flange structure transfers mating torque directly into the panel rather than through the connector body, preventing rotation during field installation under awkward access conditions.
Q: What panel thickness range can your 7/16 flange connectors accommodate?
A: Standard configurations suit common transmitter and equipment shelter panels. For non-standard thicknesses, customized body lengths or spacer hardware can be supplied.
Q: Are your 7/16 flange mount connectors suitable for pressurized feeder systems?
A: Selected configurations include gas-tight sealing interfaces suitable for pressurized feeder applications. Please state your specific pressure and sealing requirements when requesting a quote.
