Product Overview
Bulkhead mount connectors are designed to pass an RF signal through a panel or wall, creating a feed-through point that separates two compartments or environments. The 4.1-9.5 bulkhead mount series from Yangzhou Jingcheng Electronics achieves this with a threaded barrel body that installs through a standard chassis cutout and is secured with a lock nut on the reverse side — a fast, tool-accessible installation that requires no special equipment. Our bulkhead connectors are available in jam-nut, hex-nut, and round-nut configurations, with and without cable termination on the rear port, and can serve as the interface between an internal cable assembly and an external cable run.
Key Features
Standard threaded barrel allows installation through industry-standard 4.1-9.5 chassis hole cutout — direct replacement for installed base connectors
Jam-nut, hex-nut, and round-nut locking options to suit different panel thickness ranges and torque requirements
Front and rear mating interface ensures universal interoperability with compatible mating connectors
High-cycle mating durability: connector plating and contact spring geometry engineered for hundreds of mating cycles
Available with solder, crimp, and clamp cable termination options on the cable-side port
Passivation-treated stainless steel body as standard for outdoor installations; electroless nickel or gold plating on request
Low contact resistance achieved through controlled plating thickness and precision spring contact design
IP67 sealing achievable with optional O-ring kits, suitable for exposed outdoor installation points
Competitive Advantages
Interchangeability Guarantee: Our bulkhead connectors are dimensionally verified against industry-recognized specifications to ensure drop-in mechanical interchangeability with competitor products in the field — critical for maintenance and upgrade scenarios.
Field-Proven Reliability: Hundreds of thousands of units deployed globally through our export network to major regional markets confirm the long-term reliability of our designs.
Performance Verified by Network Analyzer: Every production batch is sampled and verified on our network analyzers — not just dimensional inspection — ensuring RF performance matches specifications at deliver
Rapid Prototype-to-Volume: Our vertically integrated factory enables prototype delivery within days and volume production scale-up without supply chain delays from sub-contractors.
Typical Applications
Antenna port feed-through points on base station equipment enclosures
Cabinet and shelter wall penetrations for RF distribution cabling
Panel-mount RF termination points in DAS head-end equipment rooms
Test fixture and RF shielded enclosure (RF chamber) feed-throughs
Marine and heavy-duty vehicle communication equipment chassis penetrations
Industrial automation RF monitoring system panel interfaces
Broadcast and professional audio-visual equipment rack panels
FAQ
Q: What panel thickness range do your bulkhead connectors support?
A: Standard configurations support panel thicknesses up to 3 mm for sheet metal/PCB and up to 6 mm for thicker panels. Custom thread lengths are available for non-standard requirements.
Q: How do you prevent galvanic corrosion between the connector body and aluminum enclosures?
A: We supply stainless steel bodies as standard to minimize galvanic potential with aluminum. For enhanced protection, conductive finishes or pre-applied anti-corrosion grease are available as options.
Q: Are your bulkhead connectors compatible with existing 4.1-9.5 hardware from other manufacturers?
A: Yes. The interface dimensions are verified to ensure full mechanical and electrical interoperability with all compatible 4.1-9.5 mating connectors in the field.
