SMB RF Coaxial Connectors

TYPE SMB Products are one kind of low power miniature RF coaxial connectors with snap-on coupling mechanism. Characteristic impedance is 50Ώ or 75Ώ. The characteristic of connectors is in Small Volume、Light weight, excellent electrical performance, easy to use. They are widely used in Connection with RF coaxial cable in RF circuit of Radio Communication、test instrument、meter、Radio station; TV station，the base station of the microwave system.

Temperature  Range

-55～+155℃(PE Cable   -40～+85℃)

Impedance

50Ω,75Ω

Frequency Range

DC～4GHz(50Ω);0～2GHz(75Ω)

Insulation resistance

≥1000MΩ

Insertion loss

 0.30  dB/1.5GHz

Voltage Standing Wave Ratio (VSWR)

 Straight ≤1.35/3GHz



Right  angle ≤1.45/3GHz

 Durability(mating)

≥500cycles
