EnglishMMCX RF Coaxial Connectors
TYPE MMCX RF coaxial connector is a kind of Microminiature Product smaller than type MCX. Characteristic impedance is 50Ώ. The characteristics of connector is in small volume、light weight、convenient connection and reliable. They are widely used in Connection with the RF Coaxial Cables, Transmition of RF Signal, Equipments or small-sized communications Network that are demanding on systematic Volume and weight. By using Surface Mounting Technology, it is suitable for mass instrument equipment production and producing on the assembly line.
|
Temperature Range |
-55～+155℃(PE Cable -40～+85℃) |
|
Impedance |
50Ω |
|
Frequency Range |
DC～6GHz |
|
Insulation resistance |
≥1000MΩ |
|
Insertion loss |
0.18 dB/1GHz |
|
Voltage Standing Wave Ratio (VSWR): |
Straight ≤ 1.25 / 3 GHz |
|
Right angle ≤ 1.43 / 3 GHz |
|
|
Durability(mating) |
≥500 (cycles) |
